| Place of Origin: |
Jining City, Shandong Province |
| Brand Name: |
XINXINGDA |
| Model Number: |
16T |
| Minimum Order Quantity: |
1 |
| Price: |
$190,000 |
| Packaging Details: |
According to the product, smaller wooden box packaging |
| Delivery Time: |
30-90days,depending on specific customization requirements |
| Payment Terms: |
Shipment after receiving the final payment |
Description:
The "sheet reinforcement" in the name "CNC Steel Sheet Rebar Stirrup Bender" may be a misspelling or a local term for "sheet reinforcement" or "reinforcement." The standard, universal name should be "CNC Steel Sheet Rebar Stirrup Bender."
This type of equipment is an indispensable core component of modern rebar processing. It is specifically designed to efficiently and accurately bend rebar to create stirrups in various shapes (such as rectangular, square, polygonal, circular, and special-shaped). It is widely used in beams, columns, and slabs in buildings, bridges, tunnels, and other projects.
construction sites
Steel bar bending processing
Specifications:
| XDWG-16T CNC Steel Bar Sheet Metal Bending Machine |
| Processing diameter of a single reinforcing bar(mm) |
6--16 |
| Diameter of double-root reinforcing bars processing(mm) |
6--16 |
| Maximum bending angle(°) |
180 |
| Maximum traction speed(m/min) |
100 |
| Maximum bending speed(°/sec) |
1200 |
| Length accuracy(mm/m) |
±1 |
| Angle accuracy(°) |
±1 |
| Rebar efficiency(t/h) |
30/20 |
| The distance from the center axis of the bend to the inclined distance of the silo(mm) |
1400 |
| Pneumatic component brand |
AirTAC |
| Servo motor brand |
Huichuan |
| Low-voltage electrical appliance brand |
Schneider Electric |
| hydraulic system |
have |
| Hydraulic cooling system |
have |
| equipment power(KW) |
72 |
| Number of equipment operators |
1 |
| floor space(m*m) |
26*9.5 |
The main machine is equipped with a multi-specification rebar switcher, allowing threading of up to 11 reels at a time, enabling automatic switching between different specifications.
Threading can be completed in one go, allowing for a full day of continuous operation.
An optional overhead mold storage and robotic arm automatically change molds.
A servo control system ensures fully automatic, uninterrupted straightening, bending, and shearing processes.
A 12-meter material receiving rack enables continuous production of 12-meter internal stirrups and sheet steel bars.
Multi-level finished product trolleys provide separate storage for different finished product specifications.
A wide variety of graphics can be stored, allowing for direct access to any desired graphic.
Tag:
Independent research and development design, quality assurance
High-end, efficient and high-precision
Meet your customized needs
